EQ6101CTFCEV | Dongfeng Hydrogen Fuel Cell Coach
Dongfeng EQ6101CTFCFV is a 10490mm-long hydrogen fuel cell city bus, developed for urban public transport. It is equipped with a 120kW (rated)/220kW (peak) permanent magnet synchronous motor (supplied by Suzhou Jingjin Motor), paired with a 130L hydrogen storage system and a 120kW fuel cell stack, enabling a 600km range (under comprehensive conditions). The chassis adopts a 6.5T front axle, 13T rear axle, and air suspension, with dual-circuit pneumatic brakes (ABS-equipped; front-rear disc brakes optional). Its load-bearing body uses high-strength profiles; the interior features aluminum alloy handrails, ordinary interior trim, and roof-mounted air conditioning (optional electric air conditioning). It also integrates Beidou positioning, multi-camera monitoring, and USB charging ports, fully meeting the operational needs of low-carbon urban passenger transport.
Its unit load energy consumption (Ekg) is only 0.145Wh/km·kg, which meets the 2019 national new energy subsidy standards and has a maximum subsidy coefficient of 1 times. The vehicle is equipped with a satellite positioning driving recorder and ABS braking system as standard, and can be equipped with air conditioning and other configurations as an option. It is suitable for large and medium-sized urban bus systems.
As part of EMAC, DuraMac provides complete powertrain that integrated with DCEC engine, Fast-Eaton clutch, FAST-CAT transmission, Dongfeng-DANA axle and Komman air suspension, while the electrification of automobile is the certain future, Duramac also get involved with EV powertrain system.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
Advantages of Dongfeng EQ6101CTFCEV Pure Hydrogen Fuel Cell Bus
-
The vehicle structure is reasonably arranged, and the passenger area space is maximized; the front and rear overhangs and wheelbase are moderately matched, optimizing the rear space in the car, changing the problem of the narrow rear space of the bus, making the ride more comfortable
Technical Specifications
| Total Length (mm): | 10490 |
| Total Width (mm): | 2500 |
| Total Height (mm): | 3020,3400 |
| Interior Height of Compartment (mm): | 2460 |
| Wheelbase (mm): | 5100 |
| Front Suspension / Rear Suspension (mm): | 2340/3050 |
| Approach/Departure Angle (°): | 10/12 |
| Rated Total Mass (kg): | 18000 |
| Maximum Number of Occupants (persons): | 83/25-36 |
| Maximum Speed (km/h): | 69 |
| Tire Specification: | Front 2070, Rear 1860 |
DuraMac
DCEC ISL8.9 series automotive engine is four-strokes engine with 102 mm bore and 120 mm stroke, Equipped with Bosch (or BYC or Weifu) pump. engine comes with turbocharger and Air- Air intercooler. The prime power range is from 269 HP to 394 HP.
Fast Gear
The F6A Series Automated Transmission uses the FAST automatic transmission, has six front gears, the transmission ratio step arrangement is reasonable, has very outstanding fuel economy. Adopt hydraulic automatic transmission. The F6A Series Automated Transmission has six gears, each with a different reduction ratio.
EV Truck
Electric wheel dump trucks use electricity as a power source, completely abandoning traditional fuel engines. This change enables the vehicle to achieve true “zero emissions” during operation, without the emission of pollutants such as carbon monoxide, nitrogen oxides, and particulate matter in the exhaust gas, greatly reducing the pollution to the atmospheric environment.
DANA Axle
Applying the advanced technology of DANA with high efficiency, fuel economy, strong load torque, low noise,high reliability, lower procurement cost, low repair cost and lower maintenance cost.
Datong Gear
The Datong HW25712XSJ Heavy Manual No-Sync Gearbox has a torque of 2500 N.m, a gear ratio range of 14.941-1, an oil capacity of 13 L (13.5 L when equipped with a power take-off), an overall length of 993 mm, and a weight of 428 kg.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
Crane Trucks
The DFZ5258JSQSZ6D truck crane is a powerful and versatile vehicle designed for efficient lifting and transportation tasks. Equipped with a YCS06300-61 engine and a Shaanxi Auto Fast gear : 10JS120TA high-low gear with synchronizer、PTO gearbox, it provides strong and stable power for demanding operations.
Transmission Model |
Total Length(mm) |
Overall Width(mm) |
Total Height(mm) |
Maximum Speed (km/h) |
Maximum Total Mass(kg) |
| EQ6110LTFCEV | 10990 | 2550 | 3600 | 100 | 18000 |
| EQ6101CTFCEV | 10490 | 2500 | 3020,3400 | 69 | 18000 |
| EQ6900LTFCEV | 8995 | 2500 | 3540(overhead),3350 | 100 | 14500 |
| EQ6720LTFCEV | 7235 | 2240 | 2850(Built in air conditioning) | 100 | 7600 |
| ——END—— | |||||
Basic information of Dongfeng EQ6105CTBEV9 motor |
|||||
| Motor Model | TZ400XS-M120-02 | Motor Manufacturer | |||
| Location/Fuel Type | Rear-mounted/Lithium Iron Phosphate | Motor type | Permanent Magnet Motor | ||
| Rated/peak power of motor (kw) | 120/250 | Rated/peak torque (N.m) | 1300/2800 | ||
| Total battery capacity (kWh)/voltage(V) | 121 kWh/175 kWh | Cylinder Volume (L) | 840L (6140L) / 1120L (8140L) | ||
| ——END—— | |||||
Chassis Parameters And Configuration |
|||||
| Item | Standard Configuration | Optional configuration | |||
| Front Axle | 6.5T, low-floor front axle, disc brake, with self-adjusting arm and brake pad wear alarm | maintenance-free | |||
| Rear Axle | 11.5T drive axle, drum brake, with self-adjusting arm and brake pad wear alarm | maintenance-free | |||
| Suspension | Air suspension | — — | |||
| Steering | Hydraulic power steering, recirculating ball steering gear, Φ480mm four-spoke steering wheel | — — | |||
| Drive Shaft | 1 section, universal joint drive shaft | — — | |||
| Brake | Front disc, rear drum, with brake pad wear alarm and automatic adjusting arm | Front disc, rear disc | |||
| Braking System | Dual-circuit air brake, air dryer, condenser, ABS, self-adjusting arm | — — | |||
| Tire | 275/70R22.5 18PR (no spare tire), steel wheel rim | Tire pressure monitoring | |||
| Air Compressor | Oil-free piston type | — — | |||
| Other | Electronic fan | Centralized lubrication | |||
| ——END—— | |||||
Main body Assembly |
||
| Item | Standard Configuration | Optional configuration |
| Body Structure | Load-bearing body structure, welded with high-strength steel, low-temperature resistant steel and steel plates; composite material front/rear enclosure skins; whole-vehicle cathode electrophoresis; integral foaming for heat insulation | — — |
| Interior | Molded side interior trim, foamed front/rear ceiling interior trim, PVC film ceiling, aluminum alloy air duct; subway-style handrails with anti-freeze sleeves; middle passenger door front/rear pillars each with a lower passenger door bell | Advertising light box, lifting rings |
| Floor | Bamboo-woven floor | PVC floor |
| Road signs | LED route sign | LED route sign, light box route sign |
| Car doors and door pumps | Front double pneumatic inward-swinging doors (swing arm built-in), remote control key lock, anti-pinch function; emergency valve and instrument panel emergency master valve inside/outside the vehicle; middle door emergency pull door | — — |
| Side Windows | Driver’s window: aluminum frame push-pull window; others: built-in push-pull windows, color light gray | — — |
| Windscreen | Front windshield: laminated glass; rear windshield: tempered glass | — — |
| Rear View System | Steel-frame asymmetric manual rearview mirror | Rearview mirror with electric heating |
| Air Conditioning System | Roof-mounted electric air conditioner (dual temperature) | Roof-mounted electric cooling & heating air conditioner, battery thermal management system |
| Heating System | — — | Electric heater |
| Defroster | Electric defroster | — — |
| Audiovisual System | MP3 player with microphone jack, USB charging port; multi-channel video recording system (32G SD card + 6 probes + 7-inch LCD display) | MP4/MP5 on-board hard disk player, MP3 player (optional USB/SD card), 17-inch LCD display; 19-inch LCD display |
| Satellite Positioning System | Beidou satellite positioning driving recorder | With external printer |
| lamps and lanterns | Front independent lamp with surround light, LED combination headlight, electric adjustment for headlight | — — |
| windshield wiper | Opposite type | — — |
| Hatch Door | Aluminum alloy upper-flip side hatch door (pneumatic strut); aluminum alloy rear hatch door (pneumatic strut), with door handle and proximity switch | — — |
| Seat | Damped driver seat (height-adjustable), standard bus seats (29+1 seats), driver seat seatbelt alarm | — — |
| Paint | Domestic plain paint; patterns and colors as per customer requirements | Metallic paint |
| meter | Full LCD CAN instrument, with two modules | — — |
| Other | 2×4KG fire extinguishers, 6×safety hammers, passenger door emergency switch, DC890A skylight, 2×6-QW-80 batteries, front windshield sunshade, on-board terminal, 6×automatic fire extinguishers in electrical cabinets, low-speed alarm, flecked floor leather, foot pad under brake pedal | Side window curtains, DC890B skylight, lower passenger door bell, coin acceptor, electronic stop announcer, quartz sand floor leather, driver fan, aluminum plate for driver’s footrest |
| ——END—— | ||
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
